2019+ CHEVY/GMC 1500 LONG TRAVEL / MZS-C3-2

Mazzulla Offroad’s 19+ GM 1500 long travel kit is designed to get the most suspension performance out of your 2 or 4 wheel drive truck while being completely bolt on.  This system is 3” wider per side and the wheel/tire are positioned to give maximum clearance to the firewall and recommended fiberglass fenders. The coilover shock is an OEM replacement that uses the factory upper mount and bar pin style lower mount. This kit is perfect for anyone that wants to turn their stock ½ ton GM truck into a very capable offroad vehicle without a ton of fabrication or breaking the bank. Axles assemblies sold separately.

• CAD designed and engineered
• Manufactured in the USA
• Machined billet aluminum upper control arm
• Boxed plate construction
• MIG welded
• 12" wheel travel
• 100% bolt on - minor trimming required
• Teflon lined 1" and 1 1/4" uniballs
• Billet tie rod extensions
• Machined Delrin bushings
• Grade 8 zinc plated hardware
• 17-4 stainless steel heat treated uniball spacers
• Grade 8 hardware
• Machined Delrin steering stops
• Zerk fittings for convenient bushing maintenance
• Powdercoat finish

Application:

• Can be used with factory or aftermarket shock

• Can fit up to 3.0" coilover
• Can be used with 2wd or 4wd suspension
• 4wd application will need extended axle assemblies
